Stage Navigation System

Capture an optical image and use that image in the SEM GUI to navigate across the sample.

Stage Navigation System

JEOL's Stage Navigation System (standard on IT300 series SEMs and available on all 6X10 series, field emission SEMs, and select older models) allows fast navigation to precise areas of interest on the sample. The Stage Navigation System consists of a color digital camera mounted on top of the SEM sample chamber or airlock which is integrated with and embedded into the SEM software.

SNS System Overview

  • Ideal for easy point and shoot image navigation
  • Color digital camera mounted in chamber or on airlock
  • Fully integrated and embedded into the SEM GUI
  • Calibration built in- no P/Q alignment required
  • Fixed 1.5” FOV
