Triple-Quad Mass Spectrometer

JMS-TQ4000GC

JMS-TQ4000GC Triple-Quad Mass Spectrometer

The JMS-TQ4000GC Triple-Quadrupole Mass Spectrometer accurately measures trace or residual pesticides in agricultural materials, trace levels of regulated chemicals in tap water, and simplifies quantitative analysis of persistent environmental pollutants such as dioxins and PCB’s.

Our Triple Quad GC-MS/MS allows chemists to look at hundreds of samples quickly and obtain detailed analyses of target compounds.

It achieves the fastest Selected Reaction Monitoring (SRM) switching speed in the industry at 1,000 channels/sec. Chemists can analyze multiple target compounds with high accuracy.

Fast and Accurate Quantitative Values

The JMS-TQ4000GC offers three distinct technologies for high speed analysis:

  • Ion Accumulation - the short collision cell accumulates ions and ejects them in rapid pulses. The noise level of the signal is reduced by synchronizing the timing between pulsed ion ejection and signal acquisition, making high-sensitivity analysis possible.
  • Short Cell - the short collision cell accumulates the ions for a given short time and then ejects them in a pulse. The noise level of the signal can be reduced by synchronizing the timing between pulsed ion ejection and signal acquisition, making high-sensitivity analysis possible.
  • Fast GC technique – By using a capillary column with a small diameter and short length with a fast oven temperature ramp, the TQ4000GC can reduce measurement time, significantly expediting routine analysis. Because the peak widths in the Fast-GC chromatogram are narrow, high-speed transitions are required. Short collision cell technology provides enough high-speed transitions for Fast-GC measurement without any sensitivity loss.

Easier and Faster Data Analysis

With an easy-to-read layout and simple operation, the TQ4000GC data analysis software "Escrime™" was developed for simultaneous multi-component analysis. Chromatograms are arranged in a vertical column making it easy to compare samples. Combined with the compound “slideshow” function, the Escrime software makes it easy for the chemist to confirm all samples and components.

Wide Range of Organic Analyses

In addition to the standard electron ionization (EI) source, the JMS-TQ4000GC also supports optional chemical ionization (CI) and photoionization (PI) sources, enabling easy acquisition of molecular weight information. Moreover, the system is not limited to just GC-MS and also offers two types of optionally available direct probes: direct insertion probe (DIP) for insoluble compounds and direct exposure probe (DEP) for high boiling point and labile compounds.

Easy Maintenance

No tools are required to remove the ion source for maintenance. Additionally, the high pumping capacity of the vacuum system makes it possible to resume your analysis very quickly.

Key Features

  • Short collision cell for higher sensitivity, higher throughput with shorter acquisition times
  • Fastest SRM switching speed in the industry – 1000 transitions/sec
  • Rapid pulsed ion ejection without crosstalk (ion interaction among SRM channels)
  • EI (standard), CI, and PI (optional) sources
  • Easy to clean and maintain
  • Powerful and easy-to-use software for data analysis and reporting
  • Direct Probes: Direct insertion probe (DIP) and direct exposure probe (DEP)

Easier and Faster Data Analysis

Data Analysis software for Multi-Target compounds "Escrime™"

  • Total commitment to achieving an easy-to-read layout and simple operation, to support user requirements that conventional systems cannot satisfy.
  • Software designed to truly eliminate “pain points” for routine operation.
Data Analysis software for Multi-Target compounds "Escrime™"

Slideshow for Data Check (Compound Slideshow Function)

  • Calibration curves for each pesticide component and the single-column display of the chromatograms can be checked with the slideshow function.
  • Visually check the chromatograms and calibration curves that switch at a fixed timing.
  • If there is a section needing correction, halt the slideshow and reevaluate the peak.
Slideshow for Data Check (Compound Slideshow Function)

Easy Maintenance

Easy to clean-up the ion source, and Resume analysis quickly

  • No tools are required to remove the ion source.
  • Since the vacuum pump has a high evacuation capability, the measurement recovery time is extremely short.
Easy to clean-up the ion source, and Resume analysis quickly

Key Technologies

Three Technologies provide Accurate Quantitative Values Faster

The short collision cell has the capability of ion accumulation and pulsed ion ejection allowing the user to achieve the highest sensitivity and high speed measurement. Measurement time can be reduced by high speed SRM switching at 1,000 transitions/sec, the fastest in the industry. This allows the user to improve throughput for total analysis.

Technology 1 – Ion Accumulation

The short collision cell accumulates the ions and generates a pulse. Data is acquired only when an ion pulse occurs and not acquired at other times when there is only noise, thus significantly improving the signal-to-noise ratio. Delivers unprecedented high sensitivity and reproducibility.

Technology 2 – Short Cell

Using the short collision cell makes it possible to instantaneously ejects all of the ions within the cell. This provides both high selectivity with the elimination of interfering ions, as well as the industry’s fastest SRM.
Short Collision Cell Technology

Technology 3 – Fast GC

Using small-diameter, short capillary columns and rapidly increasing the temperature of the GC oven enables shorter measurement times, significantly improving the number of samples that can be processed per hour. Since the peak widths in the chromatogram are decreased, high-speed transitions are required, which is where the capability of the short collision cell really shines.
Conventional GC-MS measurement vs. Fast GC-MS measurement

Conventional GC-MS measurement

Column:
30m length,
0.25mm I.D.,
0.25μm film thicknes

Total 40min

Conventional GC-MS measurement vs. Fast GC-MS measurement

Fast GC-MS measurement

Column:
20m length,
0.18mm I.D.,
0.18μm film thicknes

Total 15min

Watch our product introduction video about our short collision cell technology.

Videos

Watch our expert, Chip Cody, introduce the new JMS-TQ4000GC Triple-Quadrupole Mass Spectrometer at the 2019 Pittcon Conference in Philadelphia
