Related Articles

• High Mass Resolution MALDI-Imaging MS: High Stability of Peak Position during Imaging MS Measurement

  Matrix-assisted laser desorption/ionization imaging mass spectrometry (MALDI-Imaging MS) is a powerful tool for the biochemical analyses of surfaces. Previously, this technique has been used to determine the spatial distribution of hundreds of unknown compounds in thinly sliced tissue sections. The mass spectral images are generated by changing the laser irradiation point at regular intervals across the sample surface and collecting a mass spectrum for each point. Time-of-flight mass spectrometers (TOFMS) are widely used as the mass analyzer for MALDI-Imaging MS because they are well matched for the MALDI ionization process. However, the fine structure of the matrix crystals and small irregularities in the tissue surface flatness can cause peak drift in the collected mass spectra that is caused by slight differences in the starting point of the flight path for the ions at each laser irradiation point. As a result, the typical reflectron type TOFMS systems have a difficult time achieving high mass resolution from spot to spot over a thinly sliced biological surface. Conversely, the JEOL JMS-S3000 “SpiralTOFTM”, which has 5-10 times longer flight path than the reflectron type TOF, is able to reduce the effect of this mass drift to achieve high mass resolution and high mass accuracy. In this work, we report the advantages of using the SpiralTOF for MALDI-Imaging MS analyses of lipids in a mouse brain tissue section.
• High Mass-Resolution MALDI-imaging MS for Drug Metabolism in Tissue Using the JMS-S3000

  The JMS-S3000 SpiralTOF is a MALDI-TOFMS, which utilizes the JEOL patented spiral ion optics system. It has a 5-10 times longer flight path than the typical reflectron type MALDI-TOFMS. As a result, it can achieve high mass-resolution to separate peaks that have the same nominal mass but have different exact masses (isobaric separation). This feature is particularly effective for MALDI-Imaging for drug metabolism, which typically consist of relatively low molecular weight compounds which are often interfered with by matrix compounds and/or surface contaminants.
• High Mass Resolution MALDI-imaging MS Using JMS-S3000 SpiralTOF and msMicroImager

  Imaging mass spectrometry using matrix-assisted laser desorption/ionization mass spectrometry (MALDI-Imaging) has been expanded during the last decade in biological applications, to assess the distribution of proteins, peptides, lipids, drugs, and metabolites in a tissue specimen. In MALDI-Imaging measurements, a laser irradiation point was scanned on a sample surface to acquire a mass spectrum at each point. Analyzing the mass spectra with two-dimensional position information, localization of compounds with inherent molecular weights can be visualized or the mass spectra for certain regions of interests (ROIs) can be created. The JMS-S3000 SpiralTOF (Fig. 1) is a MALDI-TOFMS, which utilizes the JEOL patented spiral ion optical system. It has a 5-10 times longer flight path than the typical reflectron type MALDI-TOFMS. As a result, it can achieve high mass-resolution to separate peaks that have the same nominal mass but have different exact masses (isobaric separation). On the other hand, there are some issues for analyzing high mass resolution and high lateral resolution MALDI-Imaging raw data with common imaging software options such as Biomap.
• High Mass Resolution MALDI-MS Imaging Part II: Using the "MALDIVision" from PREMIER Biosoft

  Matrix-assisted laser desorption/ionization mass spectrometry imaging (MALDI-MS Imaging) is a powerful tool for the biochemical analyses of surfaces. Previously, this technique has been used to determine the spatial distribution of hundreds of unknown compounds in thinly sliced tissue sections. The mass spectral images are generated by changing the laser irradiation point at regular intervals across the sample surface and collecting a mass spectrum for each point. Time-of-flight mass spectrometers (TOFMS) are widely used as the mass analyzer for MALDI-MS Imaging because they are well matched for the MALDI ionization process. Ultra-high mass resolution achieving isobaric peak separation is important for lipid profiling using MALDI-Imaging [1, 2]. However, the fine structure of the matrix crystals and small irregularities in the tissue surface flatness can cause peak drift in the collected mass spectra that is caused by slight differences in the starting point of the flight path for the ions at each laser irradiation point. As a result, the typical reflectron type TOFMS systems have a difficult time achieving high mass resolution from spot to spot over a thinly sliced biological surface.
• MALDI Imaging and Structural Analysis of Lipids Directly on Tissue Specimens

  In this paper, we report the use of mass spectrometry imaging and structural analysis of lipids directly on a tissue specimen, carried out by means of matrix-assisted laser desorption/ionization tandem time-of-flight mass spectrometry, using a combination of spiral orbit-type and reflectron-type time-of-flight mass spectrometers. The most intense peak observed in the mass spectrum from a brain tissue specimen was confirmed as phosphatidylcholine (34 : 1) [M+K]+, using tandem mass spectrometry. The charge remote fragmentation channels, which are characteristically observed using high-energy collision induced dissociation, contributed significantly to this confirmation. Accurate mass analysis was further facilitated by mass correction using the confirmed peak. In mass spectrometry imaging, the high resolving power of our system could separate doublet peak of less than 0.1 u diveerence, which would otherwise be problematic when using a low-resolution reflectron type time-of-flight mass spectrometer. Two compounds, observed at m/z 848.56 and 848.65, were found to be located in complementary positions on a brain tissue specimen. These results demonstrate the importance of a high-performance tandem time-of-flight mass spectrometer for mass spectrometry imaging and analysis of observed compounds, to allow distinction between biological molecules.
• MS imaging for visualizing synthetic polymers combined with KMD - MSTips - 306

  In this report, we have combined this method with the Kendrick Mass Defect (KMD) method to effectively visualize polymer series mixtures.
