Electron Optic Documents

The JSM-IT200LA SEM delivers the ultimate user experience for high through- put imaging and elemental analysis. An embedded color camera simplifies specimen navigation, advanced automation delivers crisp secondary and backscatter images in seconds, and Real-Time (Live) EDS provides instant feedback of the specimen composition for intuitive operation at any experi- ence level. This All-in-One SEM also includes high and low vacuum modes for observation of a wide range of specimen types without compromise. All of this is delivered at a great value.

CRYO ARM Bibliography

Cryo-EM has seen an enormous increase in capabilities and potential in recent years owing to a number of technological advances, e.g. direct detector devices and improved scope automation. JEOL released two electron cryo-microscopes in 2017 specifically designed for automated and unattended, continuous operation at 200 and 300 kV, the CRYO ARM™ series. A recent update on both type of CRYO ARMs has the potential of increasing the throughput well beyond the current limit of 20,000 images/day, namely north of 50,000 images/day as well as extending the resolution to nearly true atomic resolution, i.e. 1.2Å.

Cryo-SEM imaging is a powerful tool in studying the structures of electron beam and vacuum sensitive materials. These materials include: fragile biological structures such as fungi, plants, cells, etc. as well as soft or volatile samples and even liquids. Cryo-SEM offers some clear advantages by rapidly freezing a sample prior to imaging, thus maintaining the sample as close as possible to its natural state. Long dehydration and chemical fixation steps can be avoided. Inhibiting dehydration helps maintain delicate structures without shrinkage. Moreover, volatile or even liquid samples are stabilized under the electron beam. Cryo fracturing techniques allow for study of the internal microstructure of these types of vulnerable materials as well.

Cryo-EM has enjoyed an enormous ground swell in popularity ever since the advent of more stable and automated electron microscopes, suitable movie-type cameras, and improved acquisition software. Results obtained so far have been nothing short of spectacular as illustrated by several structures in EMDB and EMPIAR solved by cryo-EM to resolutions better than 1.5Å, such as EMD-31314, EMD-33707 and EMD-35984, the latter of which reaching true atomic resolution. This note describes screening of cryo-EM samples on a JEOL JEM-1400Flash with a Gatan ELSA holder before committing to an SPA run on higher-end electron cryo-microscopes, such as the JEOL CRYO ARM.

“Visualize the truth” is a hope of researchers who use various measuring equipment. Researchers who use electron microscopes as well have a desire to observe the real structure. But actually, in experiments using electron microscopes, many problems arise: They include damage regions of the specimen when it is cut for the size suited to observation, artifacts due to the staining that is applied to enhance image contrast, deformation caused by substitution of water to resin for withstanding vacuum exposure, and thermal damage to the specimen with electron-beam irradiation. As a result, the visualization of the real structure in the microscope image becomes increasingly difficult. One recommended solution is to cool the specimen, that is, “Cryo” techniques. This “Cryo Note” introduces some of the diversified cryo-techniques. We sincerely hope your challenge to observe the “real structure” will be solved by “Cryo” methods.

Scanning Electron Microscopes (SEM) support the development of new LIB technologies with morphological observation at the micrometer to nanometer scale, as well as the chemical analysis needed to create high-performance coatings and powders. Ultra-low voltage imaging combined with signal filtering in the SEM allows direct imaging and analysis of battery constituents (anode and cathode) with nanometer resolution. Additionally, one of the important aspects of the analysis is the ability to probe chemistry of the constituents at nm scale (Fig. 1). JEOL FESEM offers the ability to perform microanalysis with energy dispersive spectroscopy (EDS) at extremely low voltages to pinpoint localized makeup of the specimens and, in particular, low atomic number materials such as carbon and fluorine. Moreover, the unique JEOL Soft X-ray spectrometer (SXES) allows researchers to analyze Li.

An e-ABF is observable as a "live image" with real-time signal processing of ABF and BF signals and it shows enhanced contrast of light atoms.

In recent years with the advances in both EBSD and FE-SEM technology there have been renewed efforts at analyzing nanostructured materials at high temperatures using dedicated specimen holders and sub-stages. Although the techniques for EBSD analysis of bulk materials using heating stages have been well established [1], the requirements for nanostructured materials preparation and analysis obviously differs from bulk materials and can benefit from a miniaturized heater with smaller sample/higher temperature capacity capability [2].

The Electrostatic Dose Modulator (EDM) is a fast beam blanking system with a pre-sample electrostatic deflector that includes electronics and software control. With EDM, the beam can switch on or off in less than 50 ns. This 100,000x improvement in blanking speed results in immediate enhancement in the clarity of data taken at fast exposure times. Moreover, EDM includes a desktop control knob that allows users to easily attenuate electron dose without affecting imaging conditions. The included software interface gives TEM and STEM users direct access to EDM’s pulse width modulation parameters providing exceptional control over the dose rate on their samples – invaluable feature for beam sensitive specimen imaging and analysis.
