What makes the difference between a good SEM image and a stellar one? Imaging samples at the appropriate conditions, and that often means at very low accelerating voltage (low kV). It's time to give it a try! Every modern day scanning electron microscope (SEM) from the top of the line, ultra-high resolution field emission SEMs to the most economical entry level bench-top tungsten (W) thermionic SEMs have the capability of imaging samples at very low accelerating voltage (Low kV ). Low kV imaging has many benefits and this easily accessible function should not be overlooked.

Cryo-EM has enjoyed an enormous ground swell in popularity ever since the advent of more stable and automated electron microscopes, suitable movie-type cameras, and improved acquisition software. Results obtained so far have been nothing short of spectacular as illustrated by several structures in EMDB and EMPIAR solved by cryo-EM to resolutions better than 1.5Å, such as EMD-31314, EMD-33707 and EMD-35984, the latter of which reaching true atomic resolution. This note describes the workflow used in Single Particle Analysis (SPA) cryo-EM workflows with the Osaka framework, i.e. a set of scripts that work with SerialEM.

Effortless sample navigation using JEOL’s Stage Navigation System (SNS). This system includes a high resolution, color CMOS camera mounted on the top of the SEM sample chamber, which captures a picture of the sample mounted on the stage. From this color picture, the user can control the position of the sample.

STEM-in-SEM (Scanning Transmission Electron Microscopy in an SEM) has become a popular technique for biologists, polymer scientists and materials scientists for its ease of use, cost effectiveness and high resolution. It is especially suited to investigating the internal structure of thin film (100-200nm) samples as well as size and shape of submicron to nanometer particles. With standard SEM imaging modes on bulk samples, there are limitations in the ultimate resolution that can be achieved due in part by the beam-sample interactions. With STEM-in-SEM, the sample is very thin and the interaction volume is small. Therefore, the resolution more closely approximates the diameter of the electron beam at the exit surface of the sample allowing for high resolution; using STEM with our state of the art FE SEMs, sub-nanometer resolution is easily achieved.

STEM-in-SEM (Scanning Transmission Electron Microscopy in an SEM) has become a popular technique for biologists, polymer scientists and materials scientists for its ease of use, cost effectiveness and high resolution. It is especially suited to investigating the internal structure of thin film (100-200nm) samples as well as size and shape of submicron to nanometer particles. With standard SEM imaging modes on bulk samples, there are limitations in the ultimate resolution that can be achieved due in part by the beam-sample interactions. With STEM-in-SEM, the sample is very thin and the interaction volume is small. Therefore, the resolution more closely approximates the diameter of the electron beam at the exit surface of the sample allowing for high resolution; using STEM with our state of the art FE SEMs, sub-nanometer resolution is easily achieved.

The 2100Plus is a multi-purpose 60-200kV TEM/STEM equipped with a LaB6. The 2100Plus enhances a laboratory's imaging capabilities. Learn more here.

As seen in Ultramicroscopy, Volume 140, May 2014, Pages 37-43.

JEOL’s Three Dimensional Image Software is a program that takes stereo pair SEM images and constructs a three dimensional (3D) image of the sample surface. From this 3D image, height and contour maps can be created to provide cross sectional shape and height data. The easiest approach to creating stereo pair images is to take two images of the same area but at different tilt angles. Images can be taken with any detector, at any magnification, with high or low accelerating voltage and even in low vacuum mode. With this software, any offset to the stereo pair images can be corrected for automatically and an anaglyph image or 3D model of the surface created.

The Tilt Rotation Motor Drive Holder (TRMH) is a motorized specimen holder designed for the JCM-7000, NeoScope™. This holder provides tilt and rotation capability during image observation. Installing this holder allows for 4 axis motor control.

TEM is an ideal technique for analyzing metals to gain an understanding of their structural and elemental properties on the sub-micrometer to atomic scale.
